Product characteristics
1. High magnification 2. Remote observation
3. Advanced optical systems 4. High Resolution
5. Exquisite and durable material 6. Reliable and easy to operate
Like the class Class Class three generations of OMNI III
Brand ZIYOUHU
Model ZD-8510
Magnification, X 8x
Field of view 6.5 degrees
Lens system 26.8 mm F/1 .35
Departure distance Eye from distance 15mm
Diopter setting +5, -5
Size Overall divisions 130 * 130 * 250 mm
Weight light 1300g
Power Battery type CR123
Use time Estified battery life 10 hours(off IR)
Resolution Resolution, lp/mm 64 ~ 70lp/mm
Warranty, year 2
Target detection range
Recognition range(cloud cover) 10 meters to 1,500 meters
Waterproof Level Immersion IP X6
Operating temperature Operating temperature-40 ~ +50
Tests under white light:
When ZIYOHU ZD-8510 is observed during the day, there is a small hole in the surface of the lens cover. The light through the hole is enough to test the operation of the device. You do not need to open the lens cover. On the device you can observe yellow-green images. Even if the lens cover is opened, the image enhancement tube will not burn out. When the light is too strong, it will activate the strong light protection system and will reduce the brightness of the image. When the device is placed in a dark place again, the image will be restored in seconds.
